SkyJet Cable Blowing Machine
The SkyJET is a simple to use and consistent cable blowing device for fibre optic installers. It is suitable for cables from 4 mm to 18 mm and microducts between 10 mm to 50 mm in diameter.
الوصف
SkyJET Cable Blowing Machine
The SkyJET is a simple to use and consistent cable blowing device for fibre optic installers. It is suitable for cables from 4 mm to 18 mm and microducts between 10 mm to 50 mm in diameter.
SkyJET is driven for smooth and stable pushing force using two air motors. It can provide 300 Npushing power and 150 m/min cable speed to make it run efficiently in the field.
Constructed with tough and rugged materials, SkyJET delivers prolonged service life even under the harshest working conditions. The unit delivers consistent air control and smooth operation for varying cable sizes and pipe diameters.
Small in size and easy to set up, the SkyJET is perfect for indoor or outdoor fiber projects. It saves operators time, eliminates the need for additional people, and they leave with a finished installation.
Technicial Specifications
| Pushing Force | 0 – 300 N |
| Pushing Speed | 0 – 150 m/min |
| Cable Size | 6 – 24 mm |
| HDPE Pipe Diameter | 14 – 63 mm |
| Motor Drive | Air (Double Air Motor) |
| Air Consumption (at 12 Bar) | |
| 0 – 25 mm | 4 m³/min (150 CFM) |
| 26 – 30 mm | 5 m³/min (185 CFM) |
| 31 – 35 mm | 7 m³/min (250 CFM) |
| 36 – 40 mm | 10 m³/min (375 CFM) |
| 41 – 44 mm > | 12 m³/min (450 CFM) |
مراجعات (0)
About brand
SKYFIBERTECH
Skyfibertech is Allame Makina’s brand dedicated to advanced fiber optic cable blowing technology. Built with precision and durability, our machines deliver maximum efficiency in fiber installation projects. From air blowing machines to cable blowing accessories and testing equipment, Skyfibertech provides a complete range of solutions. Trusted worldwide, it simplifies and accelerates fiber network construction with powerful performance, easy operation, and long-lasting reliability.
